All Products

Showing 28–36 of 138 results

View All
  • Lasecomb HSP 2113 NC 20

    The Lasercomb HSP series is specially designed for work with dense and corrugated cardboard. It combines high accuracy, productivity, reliability of design. A distinctive feature of the plotter is the possibility of manufacturing counter-matrices from getinaksa / pertinaks (in the presence of a 5-spindle milling head). Models: An accessible user program with an extensive database, graphic display of the program for optical control, diagnostic system, the possibility of technical support through PartnerNet. Working head: 4 tangentially adjustable tool positions, simplicity of removal and installation of tools, various tools for drawing, creasing and cutting. Options: Adjustability of the Z-axis, 5-spindle working head for working with pertinax, ScanVec for automated scanning and vectorization of contours. Performance: up to 70 m / min Acceleration: up to 7 m / s
  • Roland RF0B

    • Year 1968
    • Size 52x72 cm
    • Water dampening
    • Chromed impression cylinder
    • Powder spray
    • Without damages
  • Heidelberg GTOZ 52

    • Size 36 x 52 cm
    • Serial Nr. 682628
    • 2 colors
    • Straight
    • Quick action plate clamps
    • Water dampening
    • Oxydry weko
    • Cylinders and gears in good condition
  • Heidelberg GTO46-1 1979

    • water dampening
    • plus version
    • No-669556
  • Stahl T50/4A

    • 1st group: 4 buckles
    • 2nd group: 4 buckles
    • Pile feeder
    • Sound hoods
    • Counter
    • New folding rollers
  • Duplo DF-1000

    Summary
    Designed principally around the needs of the digital colour user but also suitable for folding short-run litho work, the Duplo DF-1000 is amongst the most technologically advanced suction fed folders on the market. Jobs are quickly setup with automatic sheet size detection and plate setting combining to streamline the make-ready process. The compact dimensions house the suction system thereby reducing noise and making it easy to accommodate in locations where space is limited.
    Features
    • The suction feeder is a top-feeding system enabling the flawless and mark-free feeding of both litho and digital stocks. Coated and Art stocks are handled just as well as bond papers creating a versatile folder for almost any job.
    • The 2 fold plates automatically adjust based on the sheet length. The operator simply loads the paper, selects the desired fold style, chooses a quantity and the Duplo DF-1000 is ready to go.
    • The loading tray can hold up to 1000 sheets and because it is a top-feeding system the user can be sure there will be no damage caused to the print during feeding. This makes the Duplo DF-1000 particularly suitable for digital print.
    • The shingle exit tray allows on the run off-loading. The batching function briefly pauses the job at fixed intervals allowing the operator to off-load in precise sets.
    • The five most common folding styles are pre-programmed into the machine and will automatically setup based on the sheet length. In addition, the built-in memory enables custom folds to be memorised for quick access.
    • Uniquely for a suction folder, the Duplo DF-1000 uses a fan rather than a compressor. This means it is much quieter and because of the clever Duplo engineering, the fan is housed within the machine itself so there is no separate units or attachments.
    Specifications
    Input Paper Size Minimum 120 mm wide x 182 mm long
    Input Paper Size Maximum 297 mm wide x 432 mm long
    Input Paper Weight Minimum 50 to 200gsm for A4 single fold, 50 to 160gsm for A3
    Paper Quality Fine quality, recycled, art, coated, bond
    Folding Modes Single, letter, concertina, half-concertina, double parallel, custom folding
    Loading Capacity 1000 sheets (80gsm)
    Maximum Operating Speed 240 sheets/min (A4 single fold) 200 sheets/min (normal)
    Paper Feed Method Air suction, 6 fold rollers
    Paper Size Detection Automatic detection of standard paper sizes A3, B4, A4, B5, A5, B6
    Error Detection Mis-feed, double feed, paper jam
    Total/Batch Counter 4-digit addition or subtraction system
    Fold Position Adjustment 0.125mm increments
    Moving Stacker Roller/Stopper Automatic setting
    Additional Functions Folding stopper position adjustment registration, custom fold mode, non-standard paper length auto-setup, instant ready mode, thick paper mode, batch mode, power off alarm mode
  • Polar 115 EL

    • Air table
    • Photocells
    • 2 hydraulic lifts (left and right)
  • Sakurai Oliver 52

    • Year 1989
    • Maximum Sheet Size: 52x36 cm
    • Maximum Print Area: 35x50 cm
  • Siat Gramegna ECO 70N

    Please check the specifications HERE
