Special and precise positioning of front registers, overlap mode has been applied in the delivery of top sheet which can make the process be more stable
Advanced automatic tracking technology, adjusting parameters based on the cardboard size so that machine can be operated under optimum condition
Rotatable and retractable propping frame has been applied in the delivery of bottom sheet which is better for the bending cardboard
Overload protection has been used for pressing rollers which can avoid the damage of pressing rollers (patent)
The stacking table for back up can be used for the preparation of next batch top sheep without stopping the machine, pushing it into the machine along with the track, precise location, and high working efficiency (patent)
Advanced siemens PLC tracking system has been used, automatically displaying the working status and alarming if there is any fault before stopping the machine automatically.
[RD-SF270S-1400] Fingerless type corrugated carton singleFeatures
Cardboard transmission is achieved by the method of vacuum suction, it equipped with high pressure air blower as well as a muffler, with adjustable of air blowing rate, to keep flute profiles stable under high speed.
All the corrugated rolls, pressure roll, gluing roll are pneumatically controlled, and the air control unit and electrical control unit are concentrated in on cabinet, the operation side is fully enclosed.
The main structure and frame are made of cast iron, up to the thickness of 120mm, equipped with submerged lubrication system to avoid noise and keep running stable.
The shafts of corrugated and pressure roll are all heat resisting and lubricated by lubricating grease.
The corrugated roll is made of 48CrMo alloy steel treated with hardening and tempering, grinding, laser-quenching, the hardness up to HRC58o.
The pressure roll is made of 45# medium carbon steel, with the treatment of hardening and tempering, grinding and chrome plated, the roll up and down is controlled by cylinder, and equipped with buffer device.
The gluing roll is treated with grinding, mesh snicked and chrome plated on the surface, while the doctor roll has the same treatment. The glue supplying is controlled by pneumatic.
The pre-heater is made of seamless steel tube, and connected by flexible metal hose.
Specification
General parameter
Design speed 80m/min
Max running speed 40-60m/min
Design width 1400mm
Heating source Electrical or steam or oil
Temperature scope 160-200oC
Pressure of compressed air supply 0.4-0.9Mpa
Pressure of steam(if any) 0.8-1.3Mpa
Flute type Depends on customer’s requirement
Corrugating type B/UV or UVV
Diameter of rollers
Upper corrugating roller Φ270mm
Lower corrugating roller Φ266mm
Pressure roller Φ270mm
Gluing roller Φ176mm
Doctor rol Φ110mm
Pre-heater roller Φ320mm
Electrical parameter
Main drive motor 4kw 380V 50Hz
Air suction motor 7.5kw 380V 50Hz
Glue reducer motor 100w 380V 50Hz
Gluing roller gap adjusting motor 250w 380V 50Hz
Glue pump motor 2.2kw 380V 50Hz
Heating power 64kw (16pcs quartz tube heater × 4kw/pcs)
[RD-JYZ-1400] Electrical chain type shaft paper roll standFeatures
Electrical chain type shaft paper roll stand
Max width of loading paper: 1400mm
Max diameter of loading paper roll: Φ1500mm
Loading capacity: 2T/side
The operation of lifting is driven by electrical while the clamping, loosening, traverse moving etc. are driven by manual
The web tension is adjusted by manual break.
Due to the equipping of manual disc break, the adjustment of web tension is convenient.
[RD-NCDW1400] Numerical control single ply corrugatedFeatures
Working speed: 80 m/min
Max paper width: 1400mm
Cutting precision: ±1.5mm
Crosss cutting length: 300-9999mm
Equipped with 4 slitting knives
Numerical controlled by PLC touch screen, quick changing order and setting up parameter.
Driven by variable frequency motor and servo driver.
